Lopolight 2019 LED Combined Sidelights - Boats 40-164ft 2.5m Cable Silver - Vertical Mount

• Lopolight Combined Sidelight 2Nm Silver Housing - 201-004

Combined Starboard & Port Sidelight 2nm/112.5 Deg + 112.5 Deg - Silver Housing - Vertical Mount This LED navigation light consists of a single high-power LED that produces light in the specified angle utilizing a special designed PMMA light guide. The precision machined 6082 aluminium housing with an anodized surface makes the light a rugged and durable housing for the LEDs and electronics contained within. The interior is completely filled with a special potting resin making it water- and vibration proof. Produced in our in-house manufacturing facility to meet and exceed exacting standards such as EN14744 and UL1104, under a quality management system continuously surveyed by Lloyds Register Quality Assurance. Each light is subjected to final testing for a minimum of 16 hours of continuous operation bringing the total test time beyond 24 hours. This navigation light is in compliance with the following standards: COLREG72 EN14744 IEC 60945 USCG (UL1104) Together with an appropriate Control & Monitoring System, such as Lopolight's own NLC* this navigation light can form part of an IMO MSC 253(83), LY3 and LY4 compliant system. Features: Vessel size: 12m - 50m (39.4' - 164') Visibility: 2 nautical miles Intensity: 5,4cd Power consumption: 5,4 Watt; Current: 0,45A @12 VDC - 0,22A @24 VDC Operating voltage: 10 - 32 VDC Number of LEDs: 2 Light colour: Green / Red Operating temperature: -25 Deg C to +55 Deg C IP rating: IP68 Mounting: Vertical
