Pacer Black 8 AWG Primary Wire - 100'

• Length (Feet): 100'
• Upc: 840248203241
• Color: Black
• Gauge: 8 AWG

8 AWG UL Primary Wire Wire Specifications See Table AWG 8 Conductor Stranding 168/0.0100 Nom. Insulation 0.045 Nom. O.D. 0.265 Nom. Circular Mils 16800 Approx LB/M 80.0 Compliances: UL Standard 1426 BC-5W2 UL: AWM 1028/1231 ABYC: E-11.14 UL: MTW Coast Guard: 33 CFR 183.401 Subpart 1-Electrical Systems Temperature Rating: 105 Dry, 75 Wet Characteristics: Conductor: Type III annealed finely stranded tinned copper ASTM B172 Class K Insulation: -20 to 105 Flexible, Color Coded PVC Voltage Rating: 600-V Resistant to: Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture Pacer Group's UL marine wire is designed to handle the harshest marine environments. It is built to meet and exceed the most stringent specifications. This 8 AWG wire is manufactured in house to ensure the absolute highest level of quality. This wire is constructed from Type III class K tinned copper. It is designed to offer excellent flexibility and durability. The conductors are tinned with copper to resist corrosion. This process adds to the life of the wire. What type of insulation is used during the manufacturing process? Well, once the copper is tinned, the next part of the process insulates the wire. This insulation adds a PVC jacket that is flexible and durable. It is designed to protect the wire and make it resistant to a variety of hazards. Some of the hazards are; alkali, abrasion, acid, gas, oil, flame and moisture. What standards and compliances does Pacer Group's wire meet? This marine wire exceeds the standards and requirements of ABYC, NMMA and UL. Features: Stranded, tinned copper conductors Highly flexible color coded insulation Print: (For 18-8 AWG) PACER E157097 (UL)_AWG 600V BC-5W2 105 DRY, 75° WET OR MTW OR AWM 1015/1230 (1028/1231 -8AWG ONLY) VW-1 OIL RESISTANT I Applications: Point to point wiring Internal wiring of panels and motors
